ABC Switch with Three Inputs & Volume Control

This is an ABC switch with a level knob for each input, letting you have one of the three inputs going to the single output. Great when you have three guitars with different output levels.

The level knobs are at unity fully clockwise and muted when fully anti-clockwise.

The first switch selects either the A or B input, and the second switch activates C overriding whichever input is selected on the first switch.

The pedal is totally passive. If you need to power the LEDs the pedal has a Boss style 2.1mm 9v DC socket.

The pedal is built with:

• Aluminium enclosure
• Neutrik plug sockets
• 3PDT heavy duty footswitches
• Point to point wiring
• LEDs
• 2.1mm centre negative 9v DC socket

Enclosure dimensions:

120x95x34mm
