Latching Footswitch with LED

This pedal is a latching footswitch for switching channels/effects on an amp that takes a single latching footswitch with a mono 1/4" TRS cable.

The footswitch has an internal slider switch to let you set the LED state to the correct state for the function it is switching.

The LED can be powered by an internal 9v battery (not supplied) and/or via a 2.1mm 9v DC socket. Select the preferred option above.

Just add a mono cable and you are ready to go, the switch is wired to the Tip connection.

The pedal is built with:

• Aluminium enclosure
• Neutrik plug socket
• DPDT heavy duty footswitch
• LED
• Battery clip and/or 2.1mm centre negative 9v DC socket

Enclosure dimensions:

110x60x31mm
