Passive ABY Pedal

This is an ABY switch which lets you send your input to either the A or B outputs, or to both simultaneously.

Please note that passive ABY pedals can be subject to signal and tone loss, as well as ground hum in some set ups. If you want to power the LEDs then you can connect a 9v DC centre negative Boss style adatpor to the pedal's DC socket.

The pedal is built with:

• Aluminium enclosure
• Neutrik plug sockets
• 3PDT heavy duty footswitches
• Status LEDs
• 2.1mm centre negative 9v DC socket
• Point to point wiring

Enclosure dimensions:

110x60x31mm
