Quad Latching Footswitch v2

This pedal has two pairs of latching footswitches wired to two stereo sockets, perfect for setups where a single dual latching footswitch is not enough.

The front two switches (wired to tip) are set at a lower height to the back switches (wired to ring) for them not to get in the way of each other. You'll need a two stereo patch cables to connect the footswitch to your pedals and/or amps.

Each footswitch has an internal slider switch to let you set the LED to the correct channel/effect.

The LEDs are powered via a 2.1mm 9v DC socket.

The pedal is built with:

• Aluminium enclosure
• Neutrik plug sockets
• Heavy duty footswitches
• Point to point wiring
• LEDs

Enclosure dimensions:

110x60x31mm
